Single Swing Gate Operator - GG850/AS850 AC/DC - Basic Kit
Single Swing Gate Operator - GG850/AS850 AC/DC - Basic Kit - ALEKO

Alternative Views:
Price: CAD $836.57

Quantity in Stock:19

Free Shipping
Availability:: Usually Ships in 24 to 48 Hours
Product Code: GG850NOR-AC
Qty:

DETAILS Technical Specs

PRODUCT DESCRIPTION:

ALEKO GG850/AS850 Single Swing Gate Operator is designed for residential and commercial applications. It is aimed to improve your comfort level and it allows you to stay warm and dry in your vehicle. This Single Swing Opener will handle dual swinging gates up to 12 ft in length and weighing up to 850 lb. ALEKO GG850/AS850 has powerful 24VDC motor, which provides exceptional starting torque and feature soft start and stop operation. This promotes longer gate and operator life, as well as dependable performance.


No power? No problem!


Optional Built-in battery backup provides seamless operation of the gate operator and all DC control and sensing devices in the event of a power loss.
To simplify installation, ALEKO GG850/AS850 may be installed with low-cost, low-voltage wiring or in remote locations using our optional 10W, 20W or 30W Solar Panels.

FEATURES:
  • Access your gates through remote control or keypad
  • Smooth and soft start and stop function
  • Emergency Release key in case of power failure
  • Dual/Single gate running mode
  • Optional master and slave gate running
  • Adjustable opening/closing interval between master and slave gate
  • Stop/Reverse in case of obstruction during gate opening/closing
  • The force of the motor can be programmed
  • Optional photocell protection (not included)
  • Built in adjustable auto-close (programmable from 0-99 sec)
  • Digital display indicates the running situation and setting menu
  • Reliable electromagnetic limit switches improve adjustment of the 'open' and 'close' position
ALEKO® GG850 AC/DC Single Swing Gate Operator. How it works.
Package Includes
  • - 1 (One) Actuator
  • - 1 (One) Control Box
  • - 2 (Two) 8 1/2" x 11" Warning Signs
  • - 2 (Two) Release key
  • - 2 (Two) 433MHz remotes LM122
  • - 1 (One) Set of accessories and mounting hardware for easy installation
  • - 1 (One) User Manual with step by step installation instructions
  • - Wire Sold Separately

Average Rating: Average Rating: 4 of 5 4 of 5 Total Reviews: 1 Write a review »

  0 of 0 people found the following review helpful:

4 of 5 GG850 Single Gate Basic Kit for Doug D March 22, 2022
Reviewer: Doug D from Aldergrove, BC Canada
It was easy to order and have the unit shipped.  However, the WEB SITE clearly stated the controller for the GG850 can be connected to 220VAC.   Checking the controller is was labelled as 110VAC only on the outside and inside the unit.  When calling customer service I was advised that the 220VAC unit was no longer available.  The customer service rep kept advising that I needed to connect it to 110 VAC and it took a while to convince that I ordered based on the information on the WEB SITE.  We both looked at the website while on the call and the service rep confirmed the information was outdated and will request internally that it be updated.  In now have to change the panel to provide 110VAC and buy an additional breaker.   I have not installed the unit at this time.  I will update the review once this is done.
